HPS2G.LA

Art.Nr.:
HPS2G.LA
Power Supply:
AC/DC 24V (±10%)
Relay Switching Output:
SPDT Output Switching Load 3 A
Sensor Type:
Electrolytic conductance
Protection:
IP54 to IEC60529
LEDs:
Green= Normal Operation, Red= Condensation
Measured:
Conductive water or similar liquids
Switching Hysteresis:
±5% r.h.
Preisanzeige nur für freigeschaltete Kunden

Beschreibung
The HPS2- Series (H_cs) is designed to prevent dew formation on pipes or flat surfaces. The Pipe / Surface Condensation Switch is available with extended passive te.
The Pipe / Surface Condensation Switch has two Status LED's. The Pipe / Surface Condensation Switch operates with lower power supply. The relay switching outputs are potential free (SPDT).
Use

Compatible to all common HVAC DDC and Analog Controls systems, with/without Building Automation System.
Used in all common HVAC applications.
Used in Commercial and Industrial Buildings.

Features
Low voltage, relay switching output.
Condensation detection of conductive water or similar liquids via a sensor plate below the housing.
LED's for Status Detection.
Status LED's can be enabled.
The extends, passive temperature sensor is available as NTC or PT characteristics.
Calibration potentiometer for the measuring sensitivity.
Professional and practical product design, withstands rough environmental conditions.
Easy to use, install and maintain.
Download
Download Datasheet GR AP PM DS1353en HPS2 H_cs V26_1
